MD-124 HW Manual On-screen Display and Display Configuration

B-15

Display-Setup-User Settings-Communication-Address

This is a feature for configuring a serial interface that is only available in Full Menu mode.

This menu item allows the user to set a UART address for device identification on an RS-485 or RS-422 serial

network.

Level adjust from 0-15 and reflects a unique ID number. Default is 0.

Display-Setup-User Settings-Splash Screen

This is only available in Full Menu mode.

This setting enables/disables the Splash Screen Logo when the unit is powered on, for as long as the display

controller is initalizing. The logo will disappear once the signal input appears on-screen. By factory default, the

splash shown is the Moxa logo. Please contact our customer support representatives for information on splash

screen customization.

Display Setup: Preset Defaults

Display-Setup-Load Default-Factory Default

This function will reset all settings to their factory defaults; for information on resetting the system to a set of saved

User Defaults, pleases refer to Display-Setup-Load Default-Load User Default, below. All signal inputs and

image adjustments will be reset. This function may be used in cases where you suspect a display configuration is

causing system faults. It can also be used when trouble-shooting configurations to determine if the display is the

reason for an undesirable effect, or if the problem is originating in external equipment.

Press the right (►) button to activate. A confirmation dialog will appear. Use ↑/↓ to confirm.

Display-Setup-Load Default-Load User Default

This function will restore any User Default settings that have been previously saved (to learn how to save a User

Default configuration, see Display-Setup-Load Default/Save User Default, just below). If no User Default

configuration is found, nothing will be re-configured. User defaults are custom display properties that have been

adjusted and saved by the user. This feature may be used when trouble-shooting configurations to determine if the

display is the cause of a faulty or undesirable effect, or if problems are originating in external equipment.

Press the right (►) button to activate. A confirmation dialog will appear. Use ↑/↓ to confirm.

Display-Setup-Load Default-Save User Default

This is only available in Full Menu mode.

This function will create and save a custom User Default configuration. A set of user defaults consists of the

device’s current set of display parameters as defined by the user via the OSD Menu. Saving a set of user-defined

defaults provides an alternative and completely independent configuration to the Factory Default. It is useful for

customers who want to specifically preset the OSD Menu according to a company’s networking or device policies

and specifications.

To learn how to restore a saved User Default configuration, please refer to Display-Setup-Load Default/Load

User Default, just above.

Press the right (►) button to activate. A confirmation dialog will appear. Use ↑/↓ to confirm.

Display-Setup-Direct Access (right/left arrow hotkeys)

This menu item allows the user to configure the right and left arrows to as “hotkeys” that directly access display

properties that users often find themselves fine-tuning, giving more convenient access to features that are

otherwise only accessible by navigating the OSD Menu in depth. Available assignment is Brightness, PIP Size,
