MD-119 HW Manual Display UART Command
C-5
Downloading Dual RGB File
Use the following commands for downloading dual RFGB file.
Commands Description
D2? Data: none (0 byte)
ACK: Total packet numbers (1 byte)
D2N Data: Appointed packet (1 byte)
ACK: File content (72 bytes maximum, except
for the last packet)
Uploading/Downloading Configuration Files
Uploading
Use the following command for uploading the configuration files:
Commands Description
UCF No data packet, no response
When the command is performed, wait for the
configuration files to be transmitted from the
computer to the display through
Xmodem-CRC.
Downloading
Use the following command for downloading the configuration files:
Commands Description
DCF No data packet, no response
When the command is performed, wait for the
configuration files to be received from the
display to the computer through
Xmodem-CRC.
