MD-119 HW Manual Display UART Command
C-9
0x06 0x03 0x4D 0x43 0x43 0x06 0x1D
0x82 0x41 0x33 0x32 0x33 0x32 0x72
For more MCC control commands, see the next section.
MCC Control Command
This section describes the MCC control commands that can be used to configure the display.
See the following tables.
Function Command
Description
Acknowledge (if
enabled)
Contrast control -
all channels
0x82,
“?”
“+”,“-”
Set all contrast =
value/increment/decrement
Reset
Query
Contrast red
Rane: “0” “0” – “6” “4”
Default: “3” “2”
Sharpness 0x8a,
“?”
“+”,“-”
Set sharpness =
value/increment/decrement
Reset
Query
Sharpness.
Range: “0” “0” – “0” “F”
Default: “0” “7”
Input main select 0x98,
“?”
“nn”
Select input main = PC or
VIDEO or next available
Reset
Query
Main selected.
“0x41,0x31”
ARGB1 (Default)
“0x41,0x32”
Source Layout
0x9a,
n |
“?”
Select source layout =
Single, PIP or PBP Reset
Query
Query:
“0” – Single (default)
“1” – PIP
“2” – PBP
Power Down / DPMS
Option
“0” |
“1” |
“?”
Set power down option =
On/Off
Reset
Query
”
0” – off
“
1” - on
Second source select
0xa7,
nn |
“?”
Select input second =
Video source value Reset
Query
Main selected.
“0x41,0x31” ARGB1
(Default)
“0x41,0x32” ARGB2
“0x42,0x31” Composite1
“0x42,0x32” Composite2
“0x42,0x33” Composite3
“0x43,0x31” S-video1
“0x43,0x32” S-video2
“0x43,0x33” S-video3
“0x46,0x31” DVI
Auto-setup 0xc3 Auto-setup. (PC only) “0” – fail.
“1” – successful.
