MD-124 HW Manual On-screen Display and Display Configuration

B-11

Composite signal sources may be used in this manner (i.e, as secondary input sources, or Second Source). To

implement this feature, please refer to the Display-Source-PIP-xxxx section, below.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display-Picture-Adv Settings-Graphic Scaling-Auto

This is only available in Full Menu mode and only when analog Composite/S-VHS signals are configured as the

Main Source.

With this selection, the display controller will automatically try to identify the aspect ratio of the incoming signal and

scale the source image to its proper aspect ratio, according to the best possible fit (i.e., for widest possible or tallest

possible display, according to whichever allows a complete display of the image with no loss of information). Since

this is an automatic and electronically intelligent function it may not work correctly with all signals. Users may be

forced to choose one of the other graphic scaling techniques above to get the correct/desired image appearance.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display-Picture-Adv Settings-Horz Position

Adjust the horizontal (left-to-right) position of the entire display area across the panel. This applies only to the Main

Source signal. Please note that this function can move information in the image outside the visible display area, so

use with caution.

Scale is from 0-100. 50 is the default.

Display-Picture-Adv Settings-Vert Position

Move the vertical (up-and-down) position of the panel’s entire display area. This is only applied to the Main Source

signal. Please note that this function can move image information outside the visible display area, so use caution.

Scale is from 0-100. 50 is the default.

Display-Picture-Adv Settings-RGB Calibrate

Warning! The displayed image MUST be a black/white image! Color images displayed as a gray scale are

incompatible! If a gray scale image is used, the calibration will produce incorrect color values!

This is only available in

Full Menu mode and when analog VGA/RGB signal are selected as the Main Source. This

function will automatically recalibrate the gain on the R(red), G(green), and B(blue) signals (also known as “color

intensity”) to a neutral, normalized level.

This function will override any previous color adjustments selected from the OSD menu, including Kelvin color

temperature settings. This adjustment only affects the Main Source signal.

Press the right (►) button to activate. A confirmation dialog will appear. Use ↑/ ↓ to co n fi r m .

Swap Input Sources: Main to Second / Second to Main

Display-Picture-Swap Source

This function will only be available if PIP/PBP is on; to set this property, please refer Display-Source-PIP-xxxx

and Display-Source-PBP-xxx, below.

This function swaps the source priority of the full screen and window overlay images, transferring the overlay image

into the Main Source priority, and the full screen (“Main Source”) image into the Second Source (PIP/PBP)

priority. It will transfer these images according to whatever signal inputs have been set as Main Source and

Second Source.

Press the right (►) button to activate this function. The OSD menu will still be visible.
