En-36

MS-7522 Mainboard

CH1/ CH2/ CH3 tRRD

Species the active-to-active delay of dierent banks.

CH1/ CH2/ CH3 tRTP

Time interval between a read and a precharge command.

CH1/ CH2/ CH3 tFAW

This item is used to set the tFAW timing.

Current CH1/ CH2/ CH3 tdrRdTRd/ tddRdTRd/ tsrRdTWr/ tdrRdTWr/ tddRdTWr/

tsrWrTRd/ tddWrTWr/ tsrRDTRd/ tsrWrTWr

These item show the advanced DRAM timings.

Channel 1/ Channel2 Advanced Memory Setting

Setting to [Auto] enables the advance memory timing automatically to be determined

by BIOS. Setting to [Manual] allows you to set the following advanced memory tim-

ings.

Memory Ratio

This item allows you to set the memory multiplier.

Adjusted DRAM Frequency (MHz)

It shows the adjusted DRAM frequency. Read-only.

Uncore Ratio

This item allows you to set the uncore multiplier.

Adjusted Uncore Frequency (MHz)

It shows the adjusted uncore frequency. Read-only.

QPI Conguration

Press <Enter> to enter the sub-menu.

QPI Links Speed

This item allows you to select the QPI links speed type.

QPI Frequency

This item allows you to select the QPI frequency.

ClockGen Tuner

Press <Enter> to enter the sub-menu.

CPU Amplitude Control/ PCI Express Amplitude Control

These items are used to select the CPU/ PCI Express clock amplitude.

CPU CLK Skew/ MCH CLK Skew

These items are used to select the CPU/ MCH chipset clock skew. They can help

CPU to reach the higher overclocking performance.

Adjust PCI Frequency (MHz)

This eld allows you to select the PCI frequency (in MHz).

Adjust PCI-E Frequency (MHz)

This eld allows you to select the PCIE frequency (in MHz).

▶
