Chapter 2

H110S-2P USER MANUAL

2-4-3. Installing Memory Modules

• This motherboard accommodates two memory modules. It can support

two 260-pin SO-DIMM DDR4 2133 MHz.

• Do not remove any memory module from its antistatic packaging until

you are ready to install it on the motherboard. Handle the modules only

by their edges. Do not touch the components or metal parts. Always wear

a grounding strap when you handle the modules.

• You must install at least one module in any of the two slots. Total memory

capacity is 32 GB.

• Refer to the following to install the memory modules.

C. The slot latches are levered upwards and latch on to the edges of the

DIMM.

A. Remove the cap and lift up the latches on each side of the DIMM slot.

B. Install the DIMM module into the slot and press it firmly down until it

seats c

orrectly. Check that the cutouts on the DIMM module edge

connector match the notches in the DIMM slot.
