Chapter 3
H110S-2P USER MANUAL
43
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B. X Menu
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
M.I.B. X (MB Intelligent BIOS X)
Intel(R) Core(TM) i5-6600T CPU @ 3.50GHz
Processor Speed 3500 MHz
Memory Frequency 2133 MHz
Total Memory 8192 MB
Processor Speed (3500 MHz)
This item shows the CPU speed.
Memory Frequency (2133 MHz)
This item shows the memory frequency.
Total Memory (8192 MB)
This item shows the total memory.
Intel(R) Core(TM) i5-6600T CPU @ 3.50GHz
This is display-only field and displays the information of the CPU installed in your
computer.
