Chapter 3
H110S-2P USER MANUAL
38
Device Settings (IO=3F8h; IRQ=4;)
This item shows the information of the device settings.
Change Settings (Auto)
Use this item to change device settings.
Press <Esc> to return to the Super IO Configuration page.
Press <Esc> to return to the Advanced Menu page.
Use this item to show the information of trusted computing configuration.
Trusted Computing
TPM Support (Enabled)
Use this item to enable or disable the TPM support. O.S. will not show TPM. Reset
of platform is required.
Enables or Disables BIOS
support for security device.
O.S. will not show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
TPM20 Device Found
TPM Support Enabled
Active PCR banks SHA-1
Available PCR banks SHA-1, SHA256
SHA-1 PCR bank Enabled
SHA256 PCR bank Disabled
Platform Hierarchy Enabled
Storage Hierarchy Enabled
Endorsement Hierarchy Enabled
TPM2.0 UEFI Spec Version 1.0
TPM 20 Interface Type CRB
Device Select Auto
Active PCR banks (SHA-1)
Use this item to show the Active PCR banks.
Available PCR banks (SHA-1, SHA-256)
Use this item to show the Available PCR banks.
SHA-1 PCR Bank (Enabled)
Use this item to enable or disable the SHA-1 PCR Bank.
SHA256 PCR Bank (Disabled)
Use this item to enable or disable the SHA256 PCR Bank.
