Specifications
CPU
• Intel
®
H110 ChipsetChipset
• Dual-channel SO-DIMM DDR4 memory architecture
• 2 x 260-pin DDR4 SO-DIMM sockets support up to 32 GB
• Supports DDR4 2133 MHz DDR4 SDRAM
Memory
• Supported by Intel
®
H110 Express Chipset
- 1 x Serial ATA 6Gb/s device
Storage
• 1 x DC in jack
• 3 x USB 3.0 Type A ports
• 1 x RJ45 LAN connector
• 1 x USB 3.0 Type C port
• 1 x DP port
• 1 x HDMI 1.4 port
• 1 x Microphone jack
• 1 x Headphone jack
Rear Panel I/O
• Realtek RTL8111H
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• LGA1151 socket for Intel
®
Skylake Processor
• Supports CPU up to 65W TDP
Note: Please go to ECS website for the latest CPU support list.
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x USB 2.0 header supports additional two USB 2.0 ports
• 1 x Serial SATA 6Gb/s connector
• 1 x COM header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x SATA Mode jumper
• 1 x Battery header
• 1 x Case open header
• 1 x SATA Power header
Internal I/O
Connectors &
Headers
• Realtek ALC662
- 2 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
LAN
• 2 x M.2 slots
- 1 x M.2 socket 3 key M 2280 M KEY for PCIE/SATA SSD
- 1 x M.2 socket 1 A+E key 2230 for WLAN card
Expansion
