ECS Elitegroup H110S-2P [6/62] Chapter 1 introducing the motherboard

H110S-2P

USER MANUAL

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing the H110S-2P motherboard. This motherboard is a high per-

formance, enhanced function motherboard designed to support the LGA1151 socket

for

Intel

Skylake processor.

This motherboard is based on Intel

®®

H110 Express Chipset for best desktop platform

solution. It supports up to 32 GB

of system memory with dual channel SO-DIMM DDR4

2133 MHz. Two M.2 slots are for extending usage.

It integrates USB 2.0 and USB 3.0 interface, supporting up to two USB 2.0 ports (one

USB 2.0 header supports additional two USB 2.0 ports) and four USB 3.0 ports (three

USB 3.0 Type A ports and one USB 3.0 Type C port at the rear panel) .

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including one DC in jack, one RJ45 LAN connector, three USB 3.0 Type A ports, one USB

3.0 Type C port, one Display port, one HDMI 1.4 port, one headphone jack and one

microphone jack.

In addition, this motherboard supports one SATA 6Gb/s connector for expansion.

Your motherboard package ships with the following items:

Package Contents

H110S-2P Motherboard

Quick Installation Guide

User Manual

DVD

I/O Shield

one SATA 6Gb/s cable



The package contents above are for reference only, please take the actual package items as

standard.
