![Lenovo ThinkPad T430s [103/192] Replacing a pci express mini card for wireless wan connection](/views2/1221504/page103/bg67.png)
10.ConnectthecablestothenewPCIExpressMiniCard.Besuretoattachthegraycabletotheconnector
marked“TR1”onthecard,thewhitecabletotheconnectormarked“RO”or“TR3”(center),andthe
blackcabletotheconnectormarked“TR2”.
11.Reinstallthememoryslotcoverandtightenthescrews.
12.Reinstallthebattery.See“Replacingthebattery”onpage67.
13.Turnthecomputeroveragain.Connecttheacpoweradapterandallcables.
ReplacingaPCIExpressMiniCardforwirelessWANconnection
Beforeyoustart,printtheseinstructions.
DANGER
Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.
Attention:BeforeyoustartinstallingawirelessWANcard,touchametaltableoragroundedmetalobject.
Thisactionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethecard.
IfyourcomputerisequippedwithaPCIExpressMiniCard,replacethecardbydoingthefollowing:
1.Turnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Wait
threetoveminutestoletthecomputercool.
Chapter6.Replacingdevices85
