![Lenovo thinkpad t430s, n1m2xrt [21/192] Right side view](/img/pdf.png)
Lenovo thinkpad t430s, n1m2xrt [21/192] Right side view
![Lenovo ThinkPad T430s [21/192] Right side view](/views2/1221504/page21/bg15.png)
Right-sideview
Figure2.ThinkPadT430sandT430siright-sideview
1Securitykeyhole2SerialUltrabay™Slimbay
3Wirelessradioswitch
1Securitykeyhole
Purchaseasecuritycablelockthattsthiskeyholetolockyourcomputertoastationaryobjecttoprotect
yourcomputerfromtheft.
2SerialUltrabaySlimbay
YourcomputerhasabayforSerialUltrabaySlimdevices.Anopticaldriveisinstalledinthebay.Youcan
installa9.5-mm-thickSerialUltrabaySlimdeviceinthebay.
3Wirelessradioswitch
Usethisswitchtoquicklyturnonorturnoffallwirelessconnections.
Chapter1.Productoverview3
