Chapter1.Productoverview
Thischapterprovidesinformationaboutthelocationsofconnectors,locationsofimportantproductlabels,
computerfeatures,specications,operatingenvironment,andpreinstalledThinkVantage
®
programs.
Thischaptercontainsthefollowingtopics:
•“Locatingcomputercontrols,connectors,andindicators”onpage1
•“Locatingimportantproductinformation”onpage9
•“Features”onpage11
•“Specications”onpage13
•“Operatingenvironment”onpage13
•“ThinkVantageprograms”onpage14
Locatingcomputercontrols,connectors,andindicators
Thissectionintroducesthecomputerhardwarefeaturestogiveyouthebasicinformationyouwillneed
tostartusingthecomputer.
Frontview
Figure1.ThinkPadT430sandT430sifrontview
1Built-inmicrophones(onsomemodels)2Integratedcamera(onsomemodels)
3ThinkLight
®
light4TrackPoint
®
pointingstick
5Powerbutton
6Fingerprintreader(onsomemodels)
7TrackPointbuttons8Touchpad
9Touchpadbuttons10Blackbutton
©CopyrightLenovo2012
1
