Lenovo thinkpad t430s, n1m2xrt [23/192] Bottom view
![Lenovo ThinkPad T430s [23/192] Bottom view](/views2/1221504/page23/bg17.png)
•Ifyourcomputerhasamediacardreaderslot,itsupportsthefollowingcards:
–SecureDigital(SD)card
–SecureDigitalHigh-Capacity(SDHC)card
–SecureDigitaleXtended-Capacity(SDXC)card
–MultiMediaCard(MMC)
•IfyourcomputerhasanExpressCardslot,itsupportsa34mm-widecard.
Formoreinformationaboutthesupportedcards,see“UsinganExpressCard,aashmediacard,ora
smartcard”onpage42.
5Smartcardslot
Somemodelshaveasmartcardslot.See“UsinganExpressCard,aashmediacard,orasmartcard”
onpage42.
Bottomview
Figure4.ThinkPadT430sandT430sibottomview
1PCIExpressMiniCardslotforwirelessLAN/WiMAX2PCIExpressMiniCardslotforwirelessWANormSATA
solidstatedrive
3Portreplicatorordockingstationconnector4Memory-upgradeslot
5Harddiskdriveorsolidstatedrive
6SIMcardslot
7Battery
1PCIExpressMiniCardslotforwirelessLAN/WiMAX
YourcomputermightincludeaPCIExpressMiniCardinthePCIExpressMiniCardslotwhichenables
wirelessLAN/WiMAXcommunications.
2PCIExpressMiniCardslotforwirelessWANormSATAsolidstatedrive
Yourcomputermighthaveawirelesswideareanetwork(WAN)cardinstalledinthePCIExpressMini
CardslotforwirelessWANconnections.
Forsomemodels,anmSATAsolidstatedrivemightbeinstalledinsteadofthewirelessWANcardfor
datastorage.
Chapter1.Productoverview5
