11.Pivotthecarduntilyoucansnapitintoplacebypressingtheuppersideofeachconnector1.Secure
thecardwiththescrew2.
Note:Dependingonthesystemcongurationofyourcomputer,thecardmighthaveonlyoneconnector.
12.ConnectthecablestothenewPCIExpressHalfMinicard.
Note:Dependingonthemodel,themarkingfortheconnectorsonyourcardmightlookdifferentfrom
theoneshownintheillustrationabove.BesuretoattachtheredcabletotheMAINorMconnector,
andthebluecabletotheAUXorAconnector.
13.Reinstallthememoryslotcoverandtightenthescrews.
Chapter6.Replacingdevices91
