ENGLISH

(Original instructions)

• Loosen and remove the blade retaining screw (11) by

turning it counterclockwise using the hex wrench (15).

• Remove the outer washer (10).

• Remove the saw blade (5). Warning! To reduce the risk

of serious personal injury, read, understand and follow

all important safety warnings and instructions prior to

using tool.

General Cuts

Guard against kickback

With unit unplugged, follow all assembly, adjustment and set

up instructions. Make sure lower guard operates. Select the

proper blade for the material to be cut.

• Measure and mark work for cutting.

• Support and secure work properly (See Safety Rules

and Instructions).

• Use appropriate and required safety equipment (See

Safety Rules).

• Secure and maintain work area (See Safety Rules).

• With plug inserted and guard closed, make sure switch

turns saw on and off.

Warning! It is important to support the work

properly and to hold the saw ﬁrmly to prevent loss

of control which could cause personal injury. Fig.

C illustrates recommended hand position.

Operation

Switching On and Off (fig. E)

For safety reasons the trigger switch (1) of your tool is equi-

pped with a lock-off button (21). Press the lock-off button to

unlock the tool.

To run the tool, press the trigger switch (1). As soon as the

trigger switch is released, the lock-off switch is automatically

activated to prevent unintended starting of the machine.

NOTICE: Do not switch the tool ON or OFF when the saw

blade touches the workpiece or other materials.

Sawing

Warning! To reduce the risk of serious personal

injury,always hold the tool with both hands.

• Let the blade run freely for a few seconds before starting

the cut.

• Apply only a gentle pressure to the tool while performing

the cut.

• Work with the shoe pressed against the workpiece.

Hints For Optimum Use

• As some splintering along the line of cut on the top side

of the workpiece cannot be avoided, cut on the side

where splintering is acceptable.

• Where splintering is to be minimized, e.g. when cutting

laminates, clamp a piece of plywood onto the top of the

workpiece.

Pocket cutting (Fig. K)

Pocket cutting is used to cut a hole in a piece of material

without cutting from the side.

• Measure and mark work.

• Tilt saw forward and rest front of the shoe on material to

be cut. Align so that cut will begin at the back of the

drawn rectangle shown in Fig. K.

• Using the retracting lever, retract blade guard to an

upward position, with the blade just clearing the material,

start motor and gradually lower the saw into the material.

Warning! As blade starts cutting the material,

release the retracting lever immediately.

• Never tie the blade guard in a raised position.

• When the shoe rests ﬂat on the material being cut,

complete the cut in forward direction.

• Allow the blade to come to a complete stop before lifting

saw from material.

• When starting each new cut, repeat the above steps

Wrench storage (Fig. L)

The spanner wrench (8) can be stored on the saw shoe as

shown in Fig. L.

Attaching and removing the rip fence (Fig. M)

The rip fence is used to saw in a straight line parallel to the

edge of the working piece.

Attaching

• Loosen the locking knob (17).

• Insert the rip fence (18) through the openings (19).

• Slide the rip fence into the desired position.
