Stanley stsc1618 [9/44] Assembly adjustment set up

ENGLISH

(Original instructions)

supported and balanced on a strong, stable and level

work surface. Support the work so that the wide portion

of the saw shoe is on the portion of the material that

doesn’t fall after the cut is made. Never hold cut off

piece by hand (Fig. D). Kickback from blade pinch can

result. Keep both hands on saw at all times.

• Stay alert and exercise control. Keep body positioned

to one side of blade. Always maintain a ﬁrm grip and

control of saw with both hands. Do not change hand grip

or body position while saw is running. Take precaution to

avoid injury from cut off pieces and other falling material

during operation.

Danger! Release switch immediately if blade

binds or saw stalls.

Features (Fig. E)

This tool includes some or all of the following features.

1. Trigger switch

2. Main Handle

3. Secondary Handle

4. Shoe

5. Saw Blade

6. Lower blade guard

7. Blade Guard Retracting Lever

8. Saw Blade Spanner Wrench

9. Bevel Adjustment Knob

10. Outer Washer

11.

15.

Blade Retaining Screw

Saw Blade Hex Wrench (Shown on Fig.I)

18.

20.

Rip Fence (Shown on Fig. M)

Inner Flange (Shown on Fig. J)

21. Lock-off button

23. Upper blade guard

Assembly/adjustment Set-up

Warning! Always unplug saw from power supply

before any of the following operations.

Adjusting the depth of cut (Fig. F and G)

The depth of cut should be set according to the thickness of

the workpiece.

• Loosen the lever (12) to unlock the saw shoe.

• Move the saw shoe (4) into the desired position. The

corresponding depth of cut can be read from the scale (13).

• Tighten the lever to lock the saw shoe in place.

• Set depth adjustment of saw such that one tooth of the

blade projects below the workpiece as shown in Fig. G.

Adjusting the bevel angle (Fig. H)

This tool can be set to bevel angles between 0° and 45°

• Loosen the locking knob (9) to unlock the saw shoe.

• Move the saw shoe (4) into the desired position. The

corresponding bevel angle can be read from the scale

(14).

• Tighten the locking knob to lock the saw shoe in place.

Attaching the blade (Fig. I and J)

• To prevent spindle rotation engage the protrusions of the

spanner wrench (8) into the holes in the outer washer

(10) as shown in Fig. I.

• Loosen and remove the blade retaining screw (11) by

turning the hex wrench (15) counter- clockwise.

• Remove the outer washer.

• Check and re-assembly inner ﬂange (20) on spindle (16).

Insure the correct side of inner ﬂange (20) faces outward

and match saw blade with diameter arbor well.

• Place the saw blade (5) onto the inner ﬂange (20),

making sure that the arrow on the blade points in the

same direction as the arrow on the tool.

• Fit the outer washer (10) on the spindle.

• Insert the blade retaining screw (11) into the hole in the

spindle.

• Prevent spindle rotation by engaging the spanne wrench

into the holes of the outer washer.

• Securely tighten the blade retaining screw by holding the

spanner wrench and turning hex wrench clockwise to

tighten the blade retaining screw.

Warning! Inner ﬂange (20) respectively marked

with “19” and “20”, match the saw blade (5) with

19mm and 20mm diameter arbor.

Removing the blade

To prevent spindle rotation, engage the protrusions of the

spanner wrench (8) into the holes in the outer washer (10).
