Appendix

- 118 -

6-2-1 Conguring2/5.1-ChannelAudio

The motherboard supports 2/5.1-channel

audio.Refer

tothefollowingforspeakercongurations.

• 2-channel audio: Headphone or Line out.

• 5.1-channelaudio:Frontspeakerout,Rearspeaker

out, and Center/Subwoofer speaker out.

6-2 ConguringAudioInputandOutput

Center/Subwoofer

Speaker Out

Line In/Mic In

RearSpeakerOut

Front Speaker

Out

Headphone

6-2-2 Creative Software Suite

Creative Alchemy

Through the Creative Alchemy, you can enable EAX effects for your games to obtain the most realistic gaming

experience.

Steps:

click the Start menu icon and search for

Creative>Creative Alchemy. On the left panel, select

the game for which you want to enable the EAX effects

and add it to the right panel. You will see the EAX

effects are enabled when the game is launched.

After installing the audio driver, click the Start menu icon

and search for the Creative Software Suite.
