- 20 -
Hardware Installation
1-6 Setting up AMD CrossFire
™
/NVIDIA
®
SLI
™
Conguration
Procedure and driver screen for enabling CrossFire/SLI technology may differ by graphics cards and
driverversion.Refertothemanualthatcamewithyourgraphicscardsformoreinformationabout
enabling CrossFire/SLI technology.
(Note1) Whenusingdualcoregraphicscards,only2-wayissupported.
(Note2) Thebridgeconnector(s)maybeneededornotdependingonyourgraphicscards.
C-2. To Enable SLI Function
After installing the graphics card driver in the operating
system, go to the NVIDIA Control Panel. Browse to the
CongureSLI, Surround, PhysX screen and ensure
Maximize 3D performance is enabled.
A. System Requirements
- Windows 10/8.1/7 operating system
- A CrossFire/SLI-supported motherboard with two or more PCI Express x16 slots and correct driver
- CrossFire/SLI-ready graphics cards of identical brand and chip and correct driver
(CurrentGPUsthatsupport3-WayCrossFiretechnologyincludetheAMDRadeon
™
HD 6800, HD 6900,
HD7800,HD7900,R9200,R7200,R9300,R7300,andRX400series.)ForthelatestGPUsupport
information,pleaserefertotheAMDwebsite.)
(Note1)
- CrossFire
(Note2)
/SLI bridge connectors
- Apowersupplywithsufcientpowerisrecommended(Refertothemanualofyourgraphicscardsforthe
powerrequirement)
B. Connecting the Graphics Cards
Step 1:
Observe the steps in "1-5 Installing an Expansion Card" and install CrossFire/SLI graphics cards on the PCI
Expressx16slots.(Tosetupa2-Way conguration, we recommendinstallingthegraphicscardsonthe
PCIEX16andPCIEX8slots.)
Step 2:
Insert the CrossFire
(Note2)
/SLI bridge connectors in the CrossFire/SLI gold edge connectors on top of the cards.
Step 3:
Plug the display cable into the graphics card on the PCIEX16 slot.
C.ConguringtheGraphicsCardDriver
C-1. To Enable CrossFire Function
After installing the graphics card driver in the operating
system, go to the AMD RADEON SETTINGS screen.
Browse to Gaming\Global Settings and ensure AMD
CrossFire is set to On.
