- 31 -
Hardware Installation
9) SATA EXPRESS (SATA Express Connectors)
Each SATA Express connector supports a single SATA Express device.
8) LED_C (RGB (RGBW) LED Strip Extension Cable Header)
Theheadercanbeusedtoconnectastandard5050RGB(RGBW)LEDstrip(12V/G/R/B/W),withmaximum
powerratingof2A(12V)andmaximumlengthof2m.
Pin No. Denition
1 12V
2 G
3 R
4 B
5 W
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
Forhowtoturnon/offthelightsoftheRGB(RGBW)LEDstrip,refertotheinstructionsonin
Chapter 2, "BIOS Setup."
ConnectoneendoftheRGB(RGBW)LEDstripextensioncabletothe
headerand the other end toyour RGB (RGBW) LED strip.The black
wire(markedwithatriangleontheplug)oftheextensioncablemustbe
connectedtoPin1(12V)ofthisheader.The12Vpin(markedwithanarrow)
on the other end of the extension cable must be lined up with the 12V of
the LED strip. Be careful with the connection orientation of the LED strip;
incorrect connection may lead to the damage of the LED strip.
12V
1
Black wire
12V of the
LED strip
