- 12 -
Hardware Installation
Internal
Connectors
2 x USB 2.0/1.1 headers
1xTrustedPlatformModule(TPM)header
1xRGB(RGBW)LEDstripextensioncableheader
1 x Thunderbolt
™
add-in card connector
1 x Clear CMOS jumper
2 x temperature sensor headers
1 x power button
1 x reset button
1 x Clear CMOS button
1 x ECO button
1 x OC button
1 x audio gain control switch
Voltage Measurement Points
2 x BIOS switches
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x DisplayPort
1 x HDMI port
1 x Thunderbolt
™
3 port (USB Type-C
™
port,withUSB3.1Gen2support)
1xUSB3.1Gen2Type-Aport(red)
5 x USB 3.1 Gen 1 ports
2xRJ-45ports
1 x optical S/PDIF Out connector
5xaudiojacks(Center/SubwooferSpeakerOut,RearSpeakerOut,LineIn/Mic
In,LineOut,Headphone)
I/O Controller iTE
®
I/O Controller Chip
Hardware
Monitor
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whetherthefan(pump)speedcontrolfunctionissupportedwilldependonthefan
(pump)youinstall.
BIOS 2x128Mbitash
Use of licensed AMI UEFI BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
