Style Creator
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● Reference 107
Style Assembly — Creating a Style
This operation lets you create the patterns (rhythm, bass and chords) that will make up
your original style.
The explanations here apply to step #5 of the Basic Procedure on page 106.
● Set up for creating a style.
• The length in measures for all
sections (excepting Fill In and
Break) can be set from this dis-
play. The Fill In and Break sec-
tions are limited to one
measure.
• You can return to this display
by pressing the [BACK] button
and redo the settings .
Set the Pattern Length of the
selected section.
[NEXT]
BASS
Select a style, section and
part to be assembled.
Indicates the
selected track.
RHYTHM 2
[BACK]
[NEXT]
[BACK]
[NEXT]
[BACK]
● Assign the pattern for each track.
Select a section to
be created.
Select a play type.
SOLO Mutes (turns off) all other tracks.
PLAY Turns the selected track on.
MUTE Mutes (turns off) the selected track.
• Keep in mind that any track
data for which the Play Type is
set to “MUTE” is not stored to
Flash ROM.
Phrase2
● Store as a Flash style to
Flash ROM by following
the on-screen instruc-
tions.
NEXTBACK
PAGE CONTROL
[NEXT]
[BACK]
105
