Yamaha PSR-9000 [48/214] Function tree
![Yamaha PSR-9000 [48/214] Function tree](/views2/1029223/page48/bg30.png)
48
Basic Operation
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Function Tree
Button/Controller
LCD title Function See
pages
10 DIGITAL STUDIO
[DIGITAL RECORDING]
SONG CREATOR
QUICK RECORD Recording a song quickly without having to make detailed settings 36
• CHORD STEP Recording accompaniment data with the Step Recording method
(similar to writing out the chords in a chord chart)
100
*
MULTI TRACK RECORD Recording sixteen song tracks independently 38
• TRACK Setting the Record method 38
• RECORD Starting/stopping recording 39
• EDIT Editing a recorded song (e.g., Quantize, Note Shift) 92
*
• SETUP Editing Setup data (e.g., Mixing Console parameters) 93
*
• SAVE/DELETE Saving the recorded song to a disk/Deleting a song in a disk 39
• STEP REC Recording a song with the Step Recording method (similar to writing
out the notes in music notation)
94
*
STYLE CREATOR
EASY EDIT Re-creating a style 107
• STYLE ASSEMBLY Re-creating a specific track of an already-created style. 107
• REVOICE Changing various parameters 108
• GROOVE & DYNAMICS Altering the timing for each section, velocity of notes for each track 109
FULL EDIT Creating a style by recording notes 110
*
• BASIC Selecting the section and track to be recorded, setting the tempo
and the beat, and so on
110
*
• SET UP Editing Setup data (voice, etc.) 112
*
• EDIT Editing various parameters (Quantize, etc.) 112
*
• STORE/CLEAR Storing the created style data to Flash ROM or clearing the created
style data
106
*
• PARA.EDIT Editing various parameters related to the Style File Format 112
*
• STEP REC Recording a style with the Step Recording method (similar to writing
out the notes in music notation)
118
*
NEW STYLE ASSEMBLY Creating a new style 107
MULTI PAD CREATOR
RECORDING Multi Pad Recording 120
• STEP REC Multi Pad Step Recording 121
*
CLEAR Clearing the recorded Multi Pad data 120
COPY Copying the recorded Multi Pad data 120
REPEAT Turning Repeat on or off 120
CHORD MATCH Turning Chord Match on or off 120
[MIXING CONSOLE]
VOL/EQ Adjusting the Volume, Pan and EQ high/low for each part 123
FILT Adjusting the Harmonic content and Brightness for each part 123
EFF DEPTH Adjusting the Effect (Reverb, Chorus and DSP) depth for each part 123
EFF TYPE Setting the Effect type/parameter for each block 124
TUNE Adjusting the pitch related parameters (e.g., Pitch Bend range, Por-
tamento time) for each part
123
M.EQ Adjusting the overall tone of the PSR-9000, in five frequency bands 125
VOICE Changing the voice for each part 123
LINE OUT Changing the Line out setting to send the output of each part to the
LINE OUT jacks.
126
11 MULTI PAD
[M.PAD BANK 1~60] Selecting a Multi Pad Bank 34, 65
[BANK VIEW]
REPEAT Turning Repeat on or off 65
CHORD MATCH Turning Chord Match on or off 65
[STOP] Stopping the Multi Pad playback 34
[1] ... [4] Playing the Multi Pads 34
12 Data dial Changing the tempo of accompaniment/song playback 42, 60
13 DEMO
[DEMO]
PSR-9000 DEMO Demo song selection/playback 52
14 VOICE EFFECT
[TOUCH] – Turning Touch response on or off 35, 55
[SUSTAIN] – Turning Sustain on or off 35, 55
[DSP(4~7)] – Turning DSP effects on or off 35, 55
[SLOW/FAST] – Setting the DSP effect variations of the selected voice part to the
SLOW or FAST
35, 55
[HARMONY/ECHO] – Turning Harmony/Echo on or off 35, 55
[POLY/MONO] – Setting the selected voice part to Poly or Mono 35, 55
46
