116 Reference ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Custom Style Recording via an External Sequence Recorder
You can create custom styles for the PSR-9000 using an external sequencer (or per-
sonal computer with sequencing software), instead of using the PSR-9000’s STYLE
CREATOR function.
■ Connections
•Connect the PSR-9000 MIDI OUT to the sequencer MIDI
IN, and the sequencer MIDI OUT to the PSR-9000 MIDI
IN.
• Make sure that the sequencer “ECHO” function is ON,
and the PSR-9000 LOCAL ON/OFF (page 151) is turned
OFF.
■ Creating the Data
• Record all sections and parts using a CM7 (C major sev-
enth) chord.
• Record the parts on the MIDI channels listed below,
using the PSR-9000’s internal tone generator. Optimum
compatibility with other instruments which are both XG
and SFF (Style File Format) compatible can be achieved
by using only the XG voices.
• Record the sections in the order listed below, with a
Marker Meta-event at the top of each section. Enter the
Marker Meta-events exactly as shown (including upper/
lower case characters and spaces).
• Also include an “SFF1” Marker Meta-event, “SInt” Marker
Meta-event and style name Meta-event at 1|1|000 (the
top of the sequence track), and the GM on Sys/Ex mes-
sage (F0, 7E, 7F, 09, 01, F7). (“Timing” in the chart is
based on 480 clocks per quarter note. “1|1|000” is clock
“0” of the first beat of the first measure).
• The data from 1|1|000 through 1|4|479 is the “Initial
Setup”, and 2|1|000 through the end of Ending B is the
“Source Pattern”.
• The timing of the Fill In AA and subsequent Marker Meta-
events will depend on the length of each section.
Part MIDI Ch.
Rhythm1 9
Rhythm2 10
Bass 11
Chord1 12
Chord2 13
Pad 14
Phrase1 15
Phrase2 16
Timing
Marker
Meta-
Event
Contents Comments
1|1|000
1|1|000
1|1|000
1|1|000
1|2|000
:
1|4|479
SFF1
Slnt
Style Name
(Sequence/Track
Name Meta-Event)
GM on Sys/Ex
Initial Setup Events
2|1|000
:
3|4|479
Main A
2 bars Main Pattern
(up to 255 bars)
Corresponds to
MAIN A
4|1|000
:
4|4|479
Fill In AA
1 bar Fill In Pattern
Corresponds to
FILL IN A
5|1|000
:
6|4|479
Intro A
2 bars Intro Pattern
(up to 255 bars)
Corresponds to
INTRO I
7|1|000
:
8|4|479
Ending A
2 bars Intro Pattern
(up to 255 bars)
Corresponds to
ENDING I
9|1|000
:
10|4|479
Main B
2 bars Intro Pattern
(up to 255 bars)
Corresponds to
MAIN B
11|1|000
:
11|4|479
Fill In BA
1 bar Fill In Pattern
Corresponds to
BREAK
12|1|000
:
12|4|479
Fill In BB
1 bar Fill In Pattern
Corresponds to
FILL IN B
13|1|000
:
14|4|479
Intro B
2 bars Intro Pattern
(up to 255 bars)
Corresponds to
INTRO II
15|1|000
:
16|4|479
Ending B
2 bars Intro Pattern
(up to 255 bars)
Corresponds to
ENDING II
17|1|000
:
18|4|479
Main C
2 bars Main Pattern
(up to 255 bars)
Corresponds to
MAIN C
19|1|000
:
19|4|479
Fill In CC
1 bar Fill In Pattern
Corresponds to
FILL IN C
20|1|000
:
21|4|479
Intro C
2 bars Intro Pattern
(up to 255 bars)
Corresponds to
INTRO III
22|1|000
:
23|4|479
Ending C
2 bars Intro Pattern
(up to 255 bars)
Corresponds to
ENDING III
24|1|000
:
25|4|479
Main D
2 bars Main Pattern
(up to 255 bars)
Corresponds to
MAIN D
26|1|000
:
26|4|479
Fill In DD
1 bar Fill In Pattern
Corresponds to
FILL IN D
Initial Setup
Source Pattern
