Vocal Harmony
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Quick Guide
33
3
Press the VOCAL HARMONY [SELECT] button.
4
Select a Vocal Harmony type.
5
Play the keyboard while singing into the microphone.
The Vocal Harmony effect can be controlled by the chords you play in the Auto
Accompaniment section (the keys to the left of the split point).
Vocal Harmony with Song Playback
The PSR-9000 can properly play back disk songs that contain Vocal Harmony data.
1-4
Use the same operation as in “Playback of Song Disks”
on page 30.
5
Turn the Vocal Harmony effect on and select a Vocal Harmony
type (see above).
6
Press the [MIC SETUP] button and set the Vocal Harmony
track.
Press the
[E]
or
[J]
button to select the bottom row of controls, then set the
VOCODER track to the appropriate setting. For details on the appropriate
track number (or MIDI channel) used for the Vocal Harmony effect, refer to
the documentation included with the disk software.
7
Start the song.
8
Sing into the microphone during song playback.
9
Stop the song.
VOCAL
HARMONY
MIC SETUP
SELECT
V.H. (9)
DSP(8)
TALK
A
B
C
D
E
For this example,
“JazzSisters” is
selected.
Split Point
Auto Accompaniment
section
PHONES MIC/LINE IN
START
/
STOP
PHONES MIC/LINE IN
31
