Basic Operation
45
Direct Access Chart
Number Function of the accessed LCD display Operation: + button listed below See pages
1 Mixing Console Volume/EQ settings (Main) MAIN VARIATION [A] 122
2 Volume/EQ settings (Accompaniment) MAIN VARIATION [B] 122
3 Volume/EQ settings (Song tracks 1 - 8) MAIN VARIATION [C] 122
4 Volume/EQ settings (Song tracks 9 - 16) MAIN VARIATION [D] 122
5 Filter settings (Main) FILL IN & BREAK [ ] 122
6 Filter settings (Accompaniment) FILL IN & BREAK [ ] 122
7 Filter settings (Song tracks 1 - 8) FILL IN & BREAK [ ] 122
8 Filter settings (Song tracks 9 - 16) FILL IN & BREAK [ ] 122
9 Effect Depth settings (Main) VOCAL HARMONY [MIC SETUP] 122
10 Effect Depth settings (Main) ENDING [I] 122
11 Effect Depth settings (Accompaniment) ENDING [II] 122
12 Effect Depth settings (Song tracks 1 - 8) ENDING [III] 122
13 Effect Depth settings (Song tracks 9 - 16) FADE IN/OUT 122
14 Effect Type settings VOICE EFFECT [DSP(4-7)] 123
15 Effect Type settings (Microphone Sound) VOCAL HARMONY [DSP(8)] 123
16 Effect Parameter settings VOICE EFFECT [SLOW/FAST] 123
17 Tune Settings (Portamento Time) VOICE EFFECT [POLY/MONO] 122
18 Tune Settings (Pitch Bend Range) PITCH BEND wheel 122
19 Tune Settings (Octave) UPPER OCTAVE [+], [-] 122
20 Tune Settings (Tuning) PART ON/OFF [R1] 122
21 Tune Settings (Tuning) PART ON/OFF [R2] 122
22 Tune Settings (Tuning) PART ON/OFF [R3] 122
23 Tune Settings (Tuning) PART ON/OFF [L] 122
24 Tune Settings (Transpose) KEYBOARD TRANSPOSE [+], [-] 122
25 Master EQ settings [MIXING CONSOLE] 125
26 Master EQ settings [MAIN MIXER] 125
27 Master EQ settings INTRO [I] 125
28 Voice selection [PART ON/OFF] 122
29 Voice selection VOICE [PIANO] - [PERCUSSION] 122
30 Voice selection INTRO [II] 122
31 Line Out settings INTRO [III] 126
32 Function Master Tuning [SOUND CREATOR] 134
33 Scale Tuning MULTI PAD [STOP] 134
34 Split Point/Fingering mode settings [AUTO ACCOMPANIMENT] 135
35 Split Point/Fingering mode settings [LEFT HOLD] 135
36 Foot Controller Volume settings Foot Volume 135
37 Footswitch 1 function assignment Footswitch 1 136
38 Footswitch 2 function assignment Footswitch 2 136
39 Modulation wheel settings MODULATION wheel 137
40 Initial Touch setting VOICE EFFECT [TOUCH] 137
41 After Touch setting VOICE EFFECT [SUSTAIN] 137
42 Registration settings REGISTRATION MEMORY [1] - [8] 139
43 Registration settings REGIST BANK [+], [-] 139
44 Registration Memory FreezeGroupSetting [FREEZE] 139
45 Voice Set settings (R1) PART SELECT [R1] 139
46 Voice Set settings (R2) PART SELECT [R2] 139
47 Voice Set settings (R3) PART SELECT [R3] 139
48 Voice Set settings (L) PART SELECT [LEFT] 139
49 Harmony/Echo settings [HARMONY/ECHO] 140
50 Video monitor settings [DEMO] 141
51 Talk Setting VOCAL HARMONY [TALK] 141
52 AutoLoad and Speaker settings [FUNCTION] 142
53 Display MIDI Bank & Program Change # VOICE [XG] - [CUSTOM VOICE] 142
54 Metronome Volume for Recording setting [DIGITAL RECORDING] 142
55 Parameter Lock settings [MEMORY] 142
56 Tap Count setting TAP TEMPO 142
57 Auto Exit Time setting PAGE CONTROL [BACK] 143
58 Language settings PAGE CONTROL [NEXT] 143
59 Style Manager Menu selection PRESET STYLE [8 BEAT] - [BALLROOM] 62
60 Loading Style into Flash ROM FLASH STYLE [I] - [VIII] 62
61 Style Selection Directory selection [DISK DIRECT] 63
62 Song Selection Directory selection SONG DIRECTORY [I] - [V] 66
63 Directory selection [SONG SETUP] 66
64 Directory selection [SONG PLAYER] 66
65 Multi Pad Repeat settings MULTI PAD [1], [2], [3], [4] 65
66 Chord Match settings MULTI PAD BANK [+], [-] 65
67 DISK/SCSI Loading Data from a Disk to Flash ROM [DISK/SCSI] 96
68 MIDI Clock setting [MIDI] 151
69 VocalHarmony Parameter settings VOCAL HARMONY [V.H.(9)] 69
70 Parameter settings VOCAL HARMONY [SELECT] 69
71 Music Database Searching the Music Database [MUSIC DATABASE] 27
72 Restoring the default tempo setting of the selected style Data dial -
73 Restoring the default tempo setting of the selected style ONE TOUCH SETTING [1] - [4] -
74 Returning to the default display (that appears when the power is turned on) [EXIT] -
75 Exiting from the Direct Access mode [DIRECT ACCESS] -
DIRECT
ACCESS
