The PSR-9000 “Functions”
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● Reference 143
■ Time
■ Language
● Computer Keyboard Types (for use with the PSR-9000)
The displays from which voices and
styles are selected automatically
change back to the previously
selected display after a short time.
(when this is not set to “NEVER”).
The Auto Exit Time parameter
determines the time that the Voice
List or Style List displays remain
before returning to the previous dis-
play. When this is set to “NEVER,”
the Voice List or Style List displays
remain indefinitely. (You can manu-
ally return to the previous display by
pressing the [EXIT] button.)
When this is set to “NEVER,” the selected
menu displays remain indefinitely until
changed manually. When set to a value
other than “NEVER,” the displays change
according the interval selected.
Screen Saver Time determines how much
time elapses before the Screen Saver func-
tion is turned on. The Screen Saver can-
cels the current display and scrolls through
the PSR-9000’s specifications. To return to
the original display, press the [CLOSE]
LCD button (which appears in the Screen
Saver) or any other panel button.
Select the appropriate type for the computer key-
board that is to be connected to the PSR-9000.
See below for details.
See page 43 for details.
• Keep in mind that some keys of
