Function Tree
● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●
Basic Operation
49
Button/Controller
LCD title Function See
pages
15 MUSIC DATABASE
[MUSIC DATABASE]
MUSIC DATABASE Selecting/searching/creating a Music Database 26, 64
16 ONE TOUCH SETTING
[1], [2], [3], [4] – Recalling various panel settings that match the selected style 24, 61
17 REGISTRATION MEMORY
[1] ... [8] – Recalling various panel settings 28
[FREEZE] – Turning the Freeze function on or off 28
[REGIST BANK 1~64] – Selecting a Registration Bank 28
18 MEMORY
[MEMORY] – Memorizing various panel settings to Registration Memory/One
Touch Setting
28, 61
19 VOICE
[PIANO] ... [SYNTHESIZER] – Selecting the PSR-9000 original preset voices 16
[PERCUSSION] – Selecting the PSR-9000 original preset percussive voices and Drum
Kits
54
[XG] – Selecting the preset XG voices 54
[ORGAN FLUTES] – Selecting/Editing the Organ Flutes 56
[CUSTOM VOICE] – Selecting the Custom voices 80
20 PART SELECT
[LEFT], [RIGHT 1], [RIGHT 2],
[RIGHT 3]
– Selecting a part for voice assignments 53
21 PART ON/OFF
[LEFT HOLD] – Turning Left Hold function on or off 55
[LEFT] – Turning LEFT part on or off 53
[RIGHT 1] – Turning RIGHT 1 part on or off 53
[RIGHT 2] – Turning RIGHT 2 part on or off 53
[RIGHT 3] – Turning RIGHT 3 part on or off 53
22 UPPER OCTAVE
[-], [+] – Transposing Upper parts (RIGHT1~3) up or down by one octave 18
23 VOCAL HARMONY
[TALK] – Calling up the Talk Settings related to the microphone sound 68
[DSP(8)] – Turning the DSP(8) effect for the microphone sound on or off 68
[V.H.(9)] – Turning Vocal Harmony on or off 68
[SELECT]
VOCAL HARMONY SELECT Selecting/producing the Vocal Harmony effect 69
[MIC SETUP]
3 BAND EQ Adjusting the gain of each band for the microphone sound 70
NOISE GATE Gating the input when the input signal from the microphone falls be-
low a specified level
70
COMPRESSOR Holding down the output when the input signal from the microphone
exceeds a specified level
70
VOCAL HARMONY Determining how the Vocal Harmony is controlled 70
MIC Determining how the microphone sound is controlled 71
