Introduction
Power Cord x1
Remote Control
(P/N:7N901052)
Projector
Package Overview
This projector comes with all the items shown below. Check
to make sure your unit is completed. Contact your dealer
immediately if anything is missing.
Due to the
difference in
applications for each
country, some regions
may have different
accessories.
Documentation:
NEC Projector CD-ROM
(P/N: 7N952291)
Quick Setup Guide
(P/N: 7N8N6421)
Important Information
(P/N: 7N8N6411)
Batteries (AAAx2)
For North America:
Limited Warranty
For Europe:
Guarantee Policy
For customers in Europe:You will nd our current valid Guarantee
Policy on our Web Site:www.nec-display-solutions.com
Security Label
Computer Cable (VGA)
(P/N:7N520087)
US (P/N: 79TC5021) EU (P/N: 79TC5031)
