Nec VE303X (VE303XG) [52/95] User controls
![Nec VE303X (VE303XG) [52/95] User controls](/views2/1302619/page52/bg34.png)
45
... English
User Controls
OVERSCAN
Overscan function removes the noise in a video image. Overscan
the image to remove video encoding noise on the edge of video
source.
OVERSCAN
V KEYSTONE
Press the or button to adjust image distortion vertically. If
the image looks trapezoidal, this option can help make the image
rectangular.
V KEYSTONE
EXIT
EXIT
ADJUST
Each I/O has
different setting of
“OVERSCAN”.
Please see more
information on Quick
Keys on page 13.
