Nec VE303X (VE303XG) [14/95] Introduction
![Nec VE303X (VE303XG) [14/95] Introduction](/views2/1302619/page14/bge.png)
7
... English
Introduction
Ports
1. SERVICE Port (for service
purpose only)
2. HDMI IN Port
3. COMPUTER IN Port
4. PC CONTROL Port
5. VIDEO IN Port
6. AUDIO IN Jack (3.5mm mini
jack)
7. Kensington
TM
Lock Port
8. AC IN Terminal
1
7
2 3 4 5 6
8
