Introduction
20 USB-B No function.
21 Number Button No function.
22 LAN No function.
23 CLEAR Clear the password while you
input the password.
24 FREEZE To pause the screen image.
Press again to resume the screen
image.
25 EXIT Exit the settings.
26 ENTER Conrm your section of items in
sub menu operation.
27 Four
Directional
Select Buttons
- Use the , , , or button
to select items or make
adjustments to your selection.
When the image is magnied
by using the D-ZOOM+ button,
the , , , or button
moves the image.
- Use as Quick Keys. Please see
page 13.
28 PAGE No function.
29 PICTURE
Mode
Select the Picture mode
from PRESENTATION,
HIGH-BRIGHT, VIDEO,
MOVIE, sRGB, BLACKBOARD,
USER1, or USER2.
30 VOL. +/- Increase/decrease speaker
volume.
31 ASPECT Use this function to choose your
desired aspect ratio. Please see
page 44.
When the
demagnied image
is displayed, the ,
, , or button is
not available to move
the image.
