74
English ...
Appendices
Specications
Optical NP-VE303 NP-VE303X
Projection System 0.55” SVGA DMD 0.55” XGA DMD
Resolution (pixels) *1 800x600 (SVGA) 1024x768 (XGA)
Lens
Manual zoom and manual focus
F=2.41 - 2.55 mm
f=21.8 - 24.0 mm @ 60”
Lamp
195W
(160W in ECO mode)
Light Output *2 *3
3000lm
Approx. 85% in ECO mode
Contrast Ratio *3
(with DYNAMIC
CONTRAST ON)
10000:1 (typical)
Image Size (Diagonal) 30 to 300 inch / 76.2 to 762.0 cm
Projection
Distance
wide 47” to 468” (1.19 to 11.9 m)
tele 52” to 516” (1.32 to 13.1 m)
Projection
Angle
wide 14.0°
tele 12.8°
*1 Effective pixels are more than 99.99%.
*2 This is the light output value (lumens) when [PICTURE MODE] is set to
[HIGH-BRIGHT] in the menu.
If any other mode is selected as [PICTURE MODE], the light output value
may drop slightly.
*3 Compliance with ISO21118-2012
