35
... English
User Controls
MAIN MENU SUB MENU SETTINGS
SETTINGS
GENERAL
ORIENTATION DESKTOP FRONT/ DESKTOP REAR/
CEILING FRONT/ CEILING REAR
HDMI SETTINGS VIDEO LEVEL (AUTO/NORMAL/
ENHANCED) /AUDIO SELECT
(HDMI/COMPUTER)
MUTE ON/OFF
VOLUME 0~20
SIGNAL
PHASE DEPEND ON SOURCE FORMAT
CLOCK DEPEND ON SOURCE FORMAT
H. POSITION DEPEND ON SOURCE FORMAT
V. POSITION DEPEND ON SOURCE FORMAT
ADVANCED
LOGO ON/OFF
CLOSED CAPTION OFF/CC1/CC2/CC3/CC4/T1/T2/T3/T4
SECURITY SECURITY/SECURITY TIMER/
CHANGE PASSWORD
TEST PATTERN
OPTIONS
GENERAL
INPUT SEARCH ON/OFF
INPUT COMPUTER/HDMI/VIDEO
FAN MODE AUTO/ HIGH ALTITUDE
INFORMATION HIDE ON/OFF
ID DISPLAY ON/OFF
BACKGROUND COLOR BLACK/ BLUE
RESET YES/ NO
LAMP SETTINGS
LAMP LIFE REMAINING
LAMP HOURS USED
ECO MODE OFF/ECO
LAMP LIFE REMINDER ON/OFF
CLEAR LAMP HOURS YES/NO
