54
English ...
User Controls
SECURITY
OFF: Choose “OFF” to be able to switch on the projector
without password verication.
ON: Choose “ON” to use security verication when turning on
the projector.
SECURITY
OFF
ON
ENTER CURRENT SECURITY CODE
SECURITY KEYWORD
EXITENTER
INVALID-KEYWORD TOO SHORT
First Time:
1. The default password : puqt
2. Use the remote to enter your password, and then press
ENTER to conrm your password.
TEST PATTERN
Press ENTER to make the selection. Then press MENU or EXIT to
close the sub menu.
The available test
pattern is GRID.
