Installation
Connecting the Projector
Make sure that the
power plug is fully
inserted into both
the projector AC IN
terminal and the wall
outlet.
E62405SP
R
Connect to Computer/Notebook
1.............................................................................................Power cord (supplied)
2...............................................................................................................HDMI cable
3........................................................................ Computer cable (VGA) (supplied)
4................................................................................................................RS232 cable
5............................................................................................................... Audio cable
To the wall outlet
1
3
4 5
2
