50
English ...
User Controls
MUTE
Choose “ON” to turn mute on.
Choose “OFF” to turn mute off.
MUTE
OFF
ON
VOLUME
Press the button to decrease the volume.
Press the button to increase the volume.
VOLUME
ADJUSTEXIT EXIT
