64
English ...
User Controls
CONTROL PANEL LOCK
When the keypad lock function is “ON”, the control panel will
be locked however, the projector can be operated by the remote
control. By selecting “OFF”, you will be able to reuse the control
panel. Press and hold the EXIT button on the projector cabinet for
about 10 seconds to turn off “CONTROL PANEL LOCK”.
CONTROL PANEL LOCK
OFF
ON
CONTROL ID
Use this feature to display the ID number of the projector when the
"ID SET" button is pressed on the remote control.
CONTROL ID
EXIT
MOVE
SELECT
CONTROL ID NUMBER
CONTROL ID OFF
CONTROL ID NUMBER
ADJUSTEXIT EXIT
CONTROL ID (ACTIVE)
EXIT EXIT
CONTROL ID NUMBER
ADJUST
CONTROL ID
OFF
ON
CONTROL ID WILL BE ENABLED.
ARE YOU SURE ?
YES NO
CONTROL ID
CONTROL ID IS DISABLED !
