xii
(continued on the next page)
Software
Drivers
AURA
ROG RAMDisk
ROG RAMCache II
ROG CPU-Z
ROG Mem TweakIt
Overwolf
CloneDrive
Kaspersky
®
Anti-Virus
DAEMON Tools Software
Winzip
ASUS Utilities
Fan Xpert 4
ROG Exclusive Features
Extreme Engine Digi+
- MicroFine Alloy Choke
- NexFET MOSFETs
- 10K Black Metallic Capacitors
Codensatation detection circuit
ROG DIMM.2 extension card with two M.2 slots
ROG APEX FAN BRACKET
ProbeIt
Start Button
Reset Button
ReTry Button
Safe Boot Button
Clear CMOS Button
MemOK! Button
LN2 Mode Jumper
Slow Mode Switch
Pause Switch
ROG RAMDisk
ROG RAMCache II
UEFI BIOS features :
- Extreme Tweaker
- Tweakers’ Paradise
- ROG SSD Secure Erase
- GPU Post
- O.C. Prole
- Graphics Card Information Preview
ROG MAXIMUS X APEX specifications summary
