xi
PRIME X399-A specications summary
Internal I/O
connectors
1 x USB 3.1 Gen 2 front panel connector
2 x USB 3.0 Gen 1 connectors support additional 4 USB ports (19-pin)
2 x USB 2.0 connectors support additional 4 USB ports
1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (both SATA & PCIE 3.0 x 4 mode)
1 x M.2_2 Socket 3 with vertical M Key, type 2242/2260/2280/22110 storage
devices support (both SATA & PCIE 3.0 x 4 mode)
1 x U.2 port
6 x SATA 6.0Gb/s connectors
1 x 4-pin W_PUMP+ connector
1 x 4-pin AIO_PUMP fan connector
1 x 4-pin CPU fan connector
1 x 4-pin CPU optional fan (CPU_OPT) connector
1 x 3-pin Cover fan (COV_FAN) connector
3 x 4-pin Chassis fan connectors
1 x 4-pin M.2 fan connector
1 x 5-pin Extension Fan (EXT_FAN) connector
1 x 2-pin Thermal sensor header
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x 4-pin EATX 12V Power connector
2 x RGB headers
1 x Front panel audio connector (AAFP)
1 x System panel connector (Q-Connector)
1 x Q_Code LED
1 x Clear CMOS header
1 x Power-on button
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI
6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ
Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log, F12
PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability WfM 2.0, DMI 3.0, WOL by PME, PXE
Support DVD
contents
Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version)
Operating
system support
Windows
®
10 64-bit
Form factor
Extended ATX Form Factor, 12”x 10.6” (30.5 cm x 26.9 cm)
• Specications are subject to change without notice.
• Visit the ASUS website for the software manual.
