Asus PRIME X399-A [10/96] Prime x399 a specifications summary
![Asus PRIME X399-A [10/96] Prime x399 a specifications summary](/views2/1307908/page10/bga.png)
x
PRIME X399-A specications summary
(continued on the next page)
ASUS Exclusive
Features
<Gaming>
AURA SYNC
3D Printing Friendly design
Turbo LAN
<EZ Management>
File Transfer
PC Cleaner
<EZ DIY>
Q-Design
- ASUS Q-Code
- ASUS Q-Connector
- ASUS Q-DIMM
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Shield
- ASUS Q-Slot
ASUS Special
Features
ASUS SafeSlot
- Protect your graphics card Investment
ASUS 5X Protection III
- ASUS SafeSlot Core - Fortied PCIe with solid soldering
- ASUS LANGuard - Protects against LAN surges, lightning strikes and
static-electricity discharges!
- ASUS Overvoltage Protection - World-class circuit-protecting power
design
- ASUS DIGI+ VRM - Digital power design
- ASUS DRAM Overcurrent Protection: Enhanced DRAM overcurrent
protection
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater
durability!
- AI Suite 3
- Ai Charger
ASUS Quiet
Thermal
Solution
Quiet Thermal Design:
- ASUS Fan Xpert 4
- ASUS Stylish MOS & M.2 heatsink Design
Back Panel I/O
Ports
1 x BIOS Flashback button
1 x Optical S/PDIF out
1 x Intel LAN (RJ45) port
2 x USB 3.1 Gen 2 ports (Type-A + USB Type-C™ [teal blue])
8 x USB 3.1 Gen 1 ports (blue)
5 x Audio jacks (Line in, Front Speaker Out, Mic in, Center/Subwoofer, Rear
Speaker Out)
