Asus PRIME X399-A [8/96] Prime x399 a specifications summary
![Asus PRIME X399-A [8/96] Prime x399 a specifications summary](/views2/1307908/page8/bg8.png)
viii
PRIME X399-A specications summary
CPU
AMD SocketTR4 socket for AMD Ryzen™ Threadripper™ processors
* Refer to www.asus.com for the CPU support list.
Chipset AMD X399
Memory
AMD Ryzen™ Threadripper™ Processors
- 8 x DIMM, max. 128GB, DDR4 3600+(O.C.)/3466(O.C.)/3333(O.C.)/3200(O.C.)/3
000(O.C.)/2800(O.C.)/2666/2400/2133 MHz, ECC and non-ECC, un-buffered
memory
- Quad channel memory architecture
* Please refer to Memory QVL (Qualied Vendors List) for details.
Expansion
slots
AMD Ryzen™ Threadripper™ Processors
- 4 x PCIe 3.0 x16 slots (support x16/x8/x16/x8)
AMD X399 chipset
- 1 x PCIe 2.0 x4 slot
- 1 x PCIe 2.0 x1 slot
Multi-GPU
support
Supports NVIDIA
®
3-Way/2-Way/Quad-GPU SLI™ Technology
Supports AMD 3-Way/2-Way/Quad-GPU CrossFireX™ Technology
Storage
AMD Ryzen™ Threadripper™ Processors*
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices support
(both SATA & PCIE 3.0 x 4 mode)
- 1 x M.2_2 Socket 3 with vertical M Key, type 2242/2260/2280/22110 storage
devices support (both SATA & PCIE 3.0 x 4 mode)
- 1 x U.2 port
AMD X399 chipset
- 6 x SATA 6Gb/s ports
* Supports PCIe RAID congurations via onboard M.2 storages for up to 8 storage
devices.
LAN
Intel
®
Ethernet Controller I211-AT
ASUS LAN Guard
ASUS Turbo LAN Utility
USB
AMD Ryzen™ Threadripper™ Processors
- 8 x USB 3.1 Gen 1 ports (8 ports at back panel[blue])
AMD X399 chipset:
- 1 x USB 3.1 Gen 2 front panel connector
- 4 x USB 3.1 Gen 1 ports (4 ports at mid-board)
- 4 x USB 2.0 ports (4 ports at mid-board)
ASMedia
®
3142 USB 3.1 Gen 2 controller
- 2 x USB 3.1 Gen 2 ports (1 x Type-A and 1 x USB Type-C™, at back panel)
(continued on the next page)
