ASUS PRIME X399-A
3-9
Chapter 3
OC Tuning
To start OC Tuning:
1. Press <F11> on your keyboard or click from the BIOS screen to open
EZ Tuning Wizard screen.
2. Select a PC scenario Daily Computing or Gaming/Media Editing, then click Next.
3. Select a Main Cooling System BOX cooler, Tower cooler, Water cooler, or I’m not
sure, then click Next.
4. After selecting the Main Cooling System, click Next then click Yes to start the OC
Tuning.
