xiii
Installation tools and components
The tools and components in the table above are not included in the motherboard package.
1 Bag of screws Phillips (cross) screwdriver
PC chassis Power supply unit
AMD SocketTR4 CPU AMD SocketTR4 compatible CPU Fan
DDR4 DIMM SATA hard disk drive
SATA optical disc drive (optional) Graphics card
M.2 SSD module (optional)
