4-4
Chapter 4: RAID Support
Chapter 4
4. When return to the RAIDXpert2 Conguration Utility menu, select the Array Size and
other detailed policies, press <Enter>. Save changes when nish.
You can specify the array size to be created. Choosing the value 0 will set the maximum
supported array size when a valid conguration is selected.
DeletingaRAIDset
Be cautious when deleting a RAID set. You will lose all data on the hard disk drives when
you delete a RAID set.
To delete a RAID set:
1. Select RAIDXpert2CongurationUtility> DeleteArray and press <Enter>. Select
the Array you want to delete and select DeleteArray, press <Enter>.
