– 10 –
XS1
RM-Y1010
The Sound Adjustment Menu
The “Sound Adjustment” menu allows you to
alter the sound settings.
To do this:
Press the MENU button and press
v to select
, then press OK to enter this menu. Next,
press
v or V to select the desired option and
press OK. Finally, read below how to operate
into each option.
Sound This option allows you to customise the Sound Effect. After selecting this
Effect option press OK. Next, press repeatedly
v or V to select:
Dolby* (Dolby Virtual, simulates the sound effect of “Dolby Surround Pro
Virtual Logic”).
Natural (Enhances clarity, detail and presence of sound by using “BBE High
Definition Sound system”**).
Dynamic (“BBE High Definition Sound system”** intensifies clarity and presence
of sound for better intelligibility and musical realism).
Off (Flat response).
Once you have selected your desired option, press OK to store.
Treble Press B or b to decrease or to increase higher-frequency sounds. Next, press OK to
store.
Bass Press B or b to decrease or to increase the lower-frequency sounds. Next, press OK
to store.
Balance Press B or b to emphasise the left or the right speaker. Next, press OK to store.
Reset Press OK to reset the sound to the factory preset levels.
Dual Press b. Next:
Sound • For a Stereo broadcast:
Press
v or V to select Stereo or Mono. Next press OK to store.
• For a bilingual broadcast:
Press
v or V to select Mono (for mono channel if available), A (for channel 1) or B
(for channel 2). Next press OK to store.
Auto Press b. Next press v or V to select On (the volume level of the channels will
Volume stay the same, independent of the broadcast signal, e.g. in the case of advertisements)
or Off (the volume level changes according to the broadcast signal). Next press OK to
store.
If you select “Dolby Virtual” on the “Sound Effect” option, the “Auto Volume” option will
automatically be switched to “Off”.
continued...
,
m
MENU
TV Speakers This option allows you to select if you want to listen the TV from the TV speakers or from an external
amplifier connected to the audio outputs on the rear of the TV.
After selecting this option, press
b. Next press repeatedly
v
or
V
to select:
Main to listen the TV from the TV set speakers.
Off to listen to the TV from an external amplifier.
Once you have selected your desired option, press OK to store.
If you have selected "Off", the volume of the external equipment can also be altered by pressing the 2 +/-
buttons of the remote control. When the volume buttons are pressed, the symbol
% will appear indicating that
the volume you are altering is not the volume of the TV set speakers, it is from the external equipment.
Audio Output This option allows you to select how to control the volume of the TV’s sepakers when an external
amplifier is connected to the TV’s audio output sockets. After selecting this option, press
b. Next
press
v
or
V
to select Variable (if you wish to use the TV’s remote control) or Fix (if you wish to
use the external amplifier’s remote control).
* Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
** This TV has been designed to create surround sound effect by simulating the sound of four speakers with two
speakers, when the broadcast audio signal is Dolby Surround encoded. The sound effect can also be improved
by connecting a suitable external amplifier (for details refer to page 39).
** The “BBE High Definition Sound system” is manufactured by Sony Corporation under license from BBE
Sound, Inc. It is covered by U.S. Patent No. 4,638,258 and No. 4,482,866. The word “BBE” and BBE Symbol
are trademarks of BBE Sound, Inc.
