REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 51 -
* A-1410-928-A H1 Board Complete
< CAPACITOR >
C9501 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C9503 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C9504 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C9505 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
< CONNECTOR >
CN9501 1-770-624-21 PIN, CONNECTOR 7P
< DIODE >
D9501 8-719-083-82 DIODE UDZS-TE17-12B
D9502 8-719-083-82 DIODE UDZS-TE17-12B
< RESISTOR >
R9501 1-216-809-11 METAL CHIP 100 5% 1/10W
R9503 1-216-864-11 SHORT CHIP 0
R9505 1-216-864-11 SHORT CHIP 0
R9510 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9511 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R9512 1-216-841-11 METAL CHIP 47K 5% 1/10W
R9513 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9514 1-216-809-11 METAL CHIP 100 5% 1/10W
R9515 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R9520 1-216-864-11 SHORT CHIP 0
< SWITCH >
S9501 1-572-595-11 SWITCH, TACTIL (REFLOW TYPE)
S9502 1-572-595-11 SWITCH, TACTIL (REFLOW TYPE)
S9503 1-572-595-11 SWITCH, TACTIL (REFLOW TYPE)
S9504 1-572-595-11 SWITCH, TACTIL (REFLOW TYPE)
S9505 1-572-595-11 SWITCH, TACTIL (REFLOW TYPE)
S9506 1-554-419-00 SWITCH, PUSH (1 KEY)
S9507 1-572-595-11 SWITCH, TACTIL (REFLOW TYPE)
S9508 1-572-595-11 SWITCH, TACTIL (REFLOW TYPE)
* A-1410-929-A H2 Board Complete
< CONNECTOR >
CN9601 1-695-209-21 PIN, CONNECTOR (PC BOARD) 15P
< DIODE >
D9600 8-719-083-82 DIODE UDZS-TE17-12B
D9601 8-719-083-82 DIODE UDZS-TE17-12B
D9602 8-719-083-82 DIODE UDZS-TE17-12B
D9603 8-719-083-82 DIODE UDZS-TE17-12B
D9604 8-719-083-82 DIODE UDZS-TE17-12B
D9605 8-719-083-82 DIODE UDZS-TE17-12B
D9606 8-719-083-82 DIODE UDZS-TE17-12B
D9607 8-719-083-82 DIODE UDZS-TE17-12B
D9608 8-719-083-82 DIODE UDZS-TE17-12B
D9609 8-719-083-82 DIODE UDZS-TE17-12B
D9610 8-719-083-82 DIODE UDZS-TE17-12B
D9611 8-719-083-82 DIODE UDZS-TE17-12B
D9612 8-719-083-82 DIODE UDZS-TE17-12B
< SOCKET >
J9600 1-568-267-11 JACK
J9601 1-565-666-12 TERMINAL, S 4P
J9602 1-580-443-11 JACK, PIN 3P
< RESISTOR >
R9600 1-216-809-11 METAL CHIP 100 5% 1/10W
R9601 1-216-809-11 METAL CHIP 100 5% 1/10W
R9602 1-216-809-11 METAL CHIP 100 5% 1/10W
R9603 1-216-864-11 SHORT CHIP 0
R9604 1-216-864-11 SHORT CHIP 0
R9605 1-216-864-11 SHORT CHIP 0
R9606 1-216-864-11 SHORT CHIP 0
* A-1302-881-A U1 Board Complete
4-097-829-01 HEAT SINK (K)
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C6000 1-126-603-11 ELECT CHIP 4.7UF 20.00% 35V
C6003 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C6004 1-126-205-11 ELECT CHIP 47UF 20.00% 6.3V
C6005 1-163-077-00 CERAMIC CHIP 0.1UF 10.00% 25V
C6006 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C6007 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6009 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C6011 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C6012 1-126-205-11 ELECT CHIP 47UF 20.00% 6.3V
C6013 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C6015 1-126-204-11 ELECT CHIP 47UF 20.00% 16V
C6016 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6017 1-216-864-11 SHORT CHIP 0
C6018 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C6020 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C6021 1-126-205-11 ELECT CHIP 47UF 20.00% 6.3V
C6022 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C6023 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C6031 1-126-205-11 ELECT CHIP 47UF 20.00% 6.3V
C6032 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V
C6033 1-162-928-11 CERAMIC CHIP 120PF 5.00% 50V
C6034 1-128-996-11 ELECT CHIP 4.7UF 20% 50V
