– 11 –
XS1
RM-Y1010
The Features Menu
The “Features” menu allows you to alter
various settings of the TV.
To do this:
Press the MENU button and press
v
twice to
select , then press OK to enter this menu.
Next, press
v
or
V
to select the desired option
and press OK. Finally, read below how to
operate into each option.
POWER SAVING
This option allows you to reduce the power consumption of this TV.
To do this:
After selecting the option, press OK. Then, press
v
or
V
to select Reduce. Next, press OK to store.
AUTO FORMAT
This option allows you to automatically change the aspect ratio of the screen.
To do this:
After selecting the option, press OK. Then, press
v
or
V
to select On (if you wish the TV set to
automatically switch the screen format according to the broadcast signal) or Off (if you wish to
keep your preference). Finally, press OK to store.
Even if you have selected “On” or “Off”, you can always modify the format of the screen by
pressing repeatedly on the remote control to select one of the following formats:
SMART: Imitation of wide screen effect for 4:3 broadcast.
4/3: Conventional 4:3 picture size, full picture
information.
14/9: Compromise between 4:3 and 16:9 picture size.
ZOOM: Widescreen format for letterbox movies.
WIDE: For 16:9 broadcast. Full picture information.
• In “SMART”, “ZOOM” and “14/9” modes, parts of the top and bottom of the screen are
cut off. Press
v
or
V
to adjust the position of the image on the screen (e.g. to read
subtitles).
• According to the format of diffussion, black bands can always appear whatever the
selected mode.
,
m
MENU
4:3
ZOOM
14:9
WIDE
SMART
continued...
FILM MODE
This option is set to Auto to improve the quality of the pictures in movement of the films. To cancel this function,
press
v or V to select Off. Finally, press OK to store.
AV2 OUTPUT / AV3 OUTPUT
The "AV2 Ouptut" and "AV3 Output" options allows you to select the source to be output from the Scart connectors
3/ and 2/ 2 so that you can record from these Scart any signal coming from the TV or from an
external equipment connected to the Scart connector 1/, 2/ and 3/ or side connectors 5
or 5 and 5.
If your VCR or DVD recorder supports SmartLink, this procedure is not necessary.
To do this:
Once you have entered into the "Features" menu as it is explained in the previous page and after selecting the option,
press OK. Then press
v
or
V
to select the desired output signal:
TV to output the aerial source.
AV1 to output sources connected to 1/.
AV2 to output sources connected to 2/ (only for AV3 Output).
AV3 to output sources connected to 3/ (only for AV2 Output).
AV5 to output sources connected to 5 or 5 and 5.
AUTO to output the signal that is being viewed on the TV.
• If you select “AUTO”, the output signal will always be the same one that is displayed on the screen.
• If you have connected a decoder to the Scart 2/ or 3/ 3 or to a VCR connected to one of these
Scarts, please remember to change back the "AV2 Output" or “AV3 Output” to “TV” for correct
unscrambling.
SMARTLINK
Both Scart connectors 2/ and 3/ support SmartLink, but they cannot support SmartLink at the
same time. This option allows you to select which of the Scart connectors you want to support SmartLink.
To do this:
Once you have entered the "Features" menu as it is explained in the previous page and after selecting the option, press
OK. Then press
v or V to select AV2 or AV3. Finally press OK to store.
CONNECTION GUIDE
Even you have already connected the external equipment to the TV set, it is important for you to follow the
instructions of this menu. If you proceed in this way, you will get the optimum picture settings related with the
optional equipment.
To do this:
1 Once you have entered the "Features" menu as it is explained in the previous page and after selecting the option,
press OK. Next press
v or V to chose the equipment you want to connect among the available: SAT (satellite),
Decoder, DVD, GAME, VIDEO or DVD rec. (DVD recorder). Next press
b to select the equipment chosen
(equipment selected also can be deleted by pressing
B). Once you have selected all the equipment to be connected,
press
v or V to select "Confirm" and press OK.
2 A new menu will appear showing you on which Scart connector of the rear of the TV should be connected each
equipment. Please connect each equipment according to this information to get the optimum picture setting of the
optional equipment.
We strongly recommend you to follow our connection proposals, but in case you do not agree press
B or b
to select "No" and next press the OK button. A new menu appears on the screen in which you can assign the
connections according to your preferences.
3 Once you have connected the optional equipment, press B or b to select "OK" and finally press the OK button
of the remote control.
S
S S
S
S
S
S
