Sony KE-P42XS1 [12/64] The set up menu
![Sony KE-P42XS1 [12/64] The set up menu](/views2/1313301/page12/bgc.png)
– 12 –
XS1
RM-Y1010
RGB CENTRING
This option is only available if an RGB source has been connected to the Scart connectors 1/ or
2/ on the rear of TV.
When viewing an RGB signal, the picture may need some adjusting. This option allows you to adjust the horizontal
picture position so that the picture is in the middle of the screen.
To do this:
Once you have entered the "Features" menu as it is explained in on page 22 and while watching an RGB source select
the “RGB Centring” option and press OK. Then press
v
or
V
to adjust the centre of the picture between –15 and
+15. Finally press OK to confirm and store.
SCREEN SAVER
This sub menu allows you to reduce the image retention.
If the following images are displayed for an extended period time, image retention (afterimage) in areas of the
screen may result due to the characteristics of this display panel:
• Black bars at the top and bottom that appear with a wide video source (letterbox picture).
• Black bars to the left and right that appear with a 4:3 video source (conventional TV broadcast).
• Video game sources.
• PC images.
• DVD on-screen menu displays.
• On-screen menus, channel numbers, etc..of connected equipment such as Set Top Box, cable modem,
VCR, etc...
To do this:
Once you have entered the “Features” menu as it is explained on page 22 and after selecting the option, press OK.
Next press
v
or
V
to select:
All White Select this option and press OK. Next press
v
or
V
to select On to turn the screen to white.
• This function finishes automatically after 30 minutes. If image retention is still present,
repeat the above.
• To cancel this function halfway, press any buttons (except the sound related buttons) on
the remote control.
Orbit Select this option and press OK. Next press
v
or
V
to select On to move the picture position.
LOGO ILLUMINATION
This option allows you to illuminate the SONY logo located on the front of the TV.
To do this:
Once you have entered the “Features” menu as it is explained on page 22 and after selecting the option, press OK.
Next press
v
or
V
to select Yes if you want to illuminate the Sony logo in blue. Finally press OK to store.
The Set Up Menu
The “Set Up” menu allows you to alter various
options on this TV.
To do this:
Press the MENU button and press
v
four times
to select , then press OK to enter this menu.
Next, press
v
or
V
to select the desired option
and press OK. Finally, read below how to
operate into each option.
LANGUAGE
This option allows you to select the language that menus are displayed in.
To do this:
After selecting the option, press OK and then proceed in the same way as in step 3 of the section
"Switching On the TV and Automatically Tuning" on page 15.
COUNTRY
This option allows you to select the country in which you wish to operate the TV set.
To do this:
After selecting the option, press OK and then proceed in the same way as in step 4 of the section
"Switching On the TV and Automatically Tuning" on page 15.
AUTO TUNING
This option allows you to automatically search for and store all available TV channels.
To do this:
After selecting the option, press OK and then proceed in the same way as in the steps 7 and 8 of
the section “Switching On the TV and Automatically Tuning” on page 16.
PROGRAMME SORTING
This option allows you to change the order in which the channels (TV Broadcast) appear on the
screen.
To do this:
After selecting the option, press OK and then proceed in the same way as in the step 9 of the section
“Switching On the TV and Automatically Tuning” on page 16.
,
m
MENU
continued...
