– 7 –
XS1
RM-Y1010
The operating instructions mentioned here are partial abstracts
from the Operating Instruction Manual. The page numbers of
the Operating Instruction Manual remain as in the manual.
SECTION 1 GENERAL
Connecting the Aerial and VCR
Stabilizing the TV set
After setting up, secure the TV set to a wall, pillar, etc, using the supplied anchor attachments, for safety
purposes.
1
Remove the two screws attached to the upper rear side
of the TV set.
2
Replace the two screws with the two supplied anchor
attachments.
3
Secure a wall anchor bracket (not supplied) to a solid wall or
pillar.
4
Pass a strong cord or chain through both holes of the anchor
attachments and then secure to a wall or pillar, etc.
• Use the supplied mains lead (Type C-4, Type BF or Type C-5, see page 9).
• Use the supplied coaxial cable for aerial connection.
or
For more details regarding VCR connection, refer to
“Connecting Optional Equipment to the TV” on
page 38.
OUT IN
VCR
1 Connect the TV plug to the mains socket (220-240V
AC, 50Hz).
2 The first time that the TV set is connected, it is usually
turned on. If the TV is off, press the
on/off button on
the TV set to turn on the TV.
The first time you switch on the TV, a Language
menu appears automatically on the TV screen.
3 Press the
V
,
v
,
B
or
b
buttons on the remote control to select your
language, then press the OK button to confirm your selection. From
now on all the menus will appear in your chosen language.
4 The Country menu appears automatically. Press the
v
or
V
button
to select the country in which you are using the TV. Press the OK
button to confirm your selection.
• If the country in which you want to use the TV set does not
appear in the list, select “Off” instead of a country.
• To avoid wrong teletext characters for cyrillic languages we
recommend selecting Russia if your own country does not
appear in the list.
Switching On the TV and Automatically Tuning
The first time you switch on your TV, a sequence of menu screens appear on the TV enabling you to: 1) choose
the language of the menu screen 2) Choose the country in which you are going to operate the TV, 3) check how
to connect optional equipment to your TV, 4) search and store all available channels (TV Broadcast) and 5)
change the order in which the channels (TV Broadcast) appear on the screen.
However, if you need to change any of these settings at a later date, you can do that by selecting the appropriate
option in the (Set Up menu) or by pressing the Auto Start Up button on the right side of TV set.
continued...
Country
Select country
Off
Ireland
Nederland
België/Belgique
Luxembourg
France
Italia
Schweiz/Suisse/Svizzera
